VTL TURRET SERIES
Model : 400 | 500 | 800 (A) | 800 (B)
CONTROL SYSTEM FEATURES
- Manual Data Input
- 2 Axis simultaneous
- Part Program Storage and Editing
- Constant Surface Speed Control
- Tool nose radius Compensation
- Feed rate override
- Circular Interpolation
- Threaded Cutting Cycle
- Direct drawing dimensions programming
- Absolute / Incremental programming
- RS-232 serial interface port
- Backlash compensation
- Graphic Simulation
- Electronic hand wheel
- Run hour display
- LCD display
- Self diagnostick
- USB Port
OPTIONAL
- 4 Jaw / 6 Jaw Power Chuck
- Automatic Pallet Changer
- Auto loading / Unloading System
- Tools Setting Probe
- Spinadla Gear Box
- Manual Chuck
| CAPACITY | UNIT | 400 | 500 | 800 (A) | 800 (B) |
| MAXIMUM SWING DIA. | MM | 600 | 750 | 1050 | 1050 |
| MAXIMUM CUTTING HEIGHT | MM | 500 | 700 | 750 | 900 |
| DAYLIGHT | MM | 500 | 700 | 750 | 900 |
| STANDARD TURNING DIA. | MM | 400 | 500 | 600 | 600 |
| CHUCK SIZE | MM | 400 | 400 | 600 | 600 |
| MAX. TURNING DIA. | MM | 550 | 700 | 800 | 800 |
| X-AXIS TRAVEL | MM | 300 | 380 | 430 | 430 |
| Z-AXIS TRAVEL | MM | 510 | 710 | 760 | 910 |
| RAPID TRANSVERSE (X-AXIS) | M/Min. | 20 | 15 | 15 | 15 |
| RAPID TRANSVERSE (Z-AXIS) | M/Min. | 15 | 15 | 15 | 15 |
| MAIN SPINDLE | |||||
| SPINDLE MOTOR (Fanuc) | KW | 11 / 15 | 11 / 15 (15 / 18) | 15 / 18 | 15 / 18 (22 / 26) |
| SPINDLE MOTOR (Siemens) | KW | 12 / 16 | 12 / 16 (15 / 18) | 15 / 18 | 15 / 18 (22 / 26) |
| SPINDLE BORE | 75 | 85 | 100 | 100 | |
| SPINDLE NOSE | A2-8 | A2-8 | A2-11 | A2-11 | |
| SPINDLE SPEED RANGE | RPM | 50-1500 | 50-1200 | 50-1000 | 50-600 |
| FUL POWER SPEED RANGE | RPM | 500-1500 | 375-1200 | 300-1000 | 300-600 |
| TURRET | BTP-100 | BTP-125 | BTP-125 | BTP-125 | |
| NUMBER OF STATION | 8 | 8 | 8 | 8 | |
| MAX. BORING BAR DIA. | 40 | 50 | 50 | 50 | |
| TOOL SIZE (CROSS SECTION) | 25 x 25 | 32 x 32 | 32 x 32 | 32 x 32 | |
| OTHERS | |||||
| WEIGHT | KG. | 3500 | 6500 | 7600 | 9300 |
| POSITIONING ACCURACY | MM | ±0.007 | ±0.009 | ±0.009 | ±0.01 |
| REPEATABILITY | MM | ±0.007 | ±0.007 | ±0.007 | ±0.007 |
