ARYA LINEAR SERIES
Model: 80/200 : 30M / Min.Rapid
CONTROL SYSTEM FEATURES
- Manual Data Input
- 2 Axis simultaneous
- Part Program Storage and Editing
- Constant Surface Speed Control
- Tool nose radius Compensation
- Feed rate override
- Circular Interpolation
- Threaded Cutting Cycle
- Direct drawing dimensions programming
- Absolute / Incremental programming
- RS-232 serial interface port
- Backlash compensation
- Graphic Simulation
- Electronic hand wheel
- Run hour display
- LCD display
- Self diagnostick
- USB Port
STANDRD FEATURES
- Hardened & Ground EN-9 Box Guideways
- AC Spindle Drive & Servo Drive
- Hydraulic Chuck with Actuating cylinder
- Hydraulic Unit, Foot Switch, Coolant System
- Centralized Lubrication System
- Electrical Quality Device
- Boring holder & Axial holder
OPTIONAL
- Chip Converyor
- Bar feeder
- Bar Puller
- Hydraulic Turret
- Stabilizer
- Auto Door
WARM UP OPERATION
- Warm up Operation in the Machine must be do when machine power on after a certain time.
- In Warm up Operation of Machine move the all Axis without job in a Progarm Cycle.
Tool Interfernce Diagram
Working Range
| CAPACITY | UNIT | 80/200 | |||||||||||
| SWING OVER BED | MM | 300 | |||||||||||
| MAXIMUM TURNING LENGTH | MM | 165 | |||||||||||
| STANDARD TURNING DIA. | MM | 80 | |||||||||||
| CHUCK SIZE | MM | 135 | |||||||||||
| MAX. TURNING DIA. | MM | 150 | |||||||||||
| X-AXIS TRAVEL | MM | 250 | |||||||||||
| Z-AXIS TRAVEL | MM | 180 | |||||||||||
| RAPID TRAVERSE | M/Min. | 30 | |||||||||||
| AXIS | |||||||||||||
| X-Z AXIS LM | 25 | ||||||||||||
| Z AXIS BALL SCREW (P x D) | 25 x 10 | ||||||||||||
| MOTOR TORQUE (Z axis) | NM | 3.7 | |||||||||||
| X AXIS BALL SCREW (P x D) | 25 x 10 | ||||||||||||
| MOTOR TORQUE (X axis) | NM | 3.7 | |||||||||||
| MAIN SPINDLE | |||||||||||||
| SPINDLE MOTOR : SIEMENS | KW | 5.5 / 3.5 | |||||||||||
| FANUC | KW | 5.5 / 3.5 | |||||||||||
| SPINDLE BORE | 38 | ||||||||||||
| SPINDLE NOSE | A2-4 | ||||||||||||
| MAXIMUM BAR CAPACITY | 25 | ||||||||||||
| SPINDLE SPEED RANGE | RPM | 50-4000 | |||||||||||
| FULL POWER SPEED RANGE | RPM | 750-3500 | |||||||||||
| TOOL | |||||||||||||
| MAX. BORING BAR DIA. | 32 | ||||||||||||
| TOOL SIZE (CROSS SECTION) | 20 x 20 | ||||||||||||
| OTHERS | |||||||||||||
| POSITIONING ACCURACY | MM | ±0.010 | |||||||||||
| REPEATABILITY | MM | ±0.005 | |||||||||||
| WEIGHT (APPROX) | KG | 1400 | |||||||||||
| SIZE | |||||||||||||
| LENGTH | MM | 1560 | |||||||||||
| WIDTH | MM | 1600 | |||||||||||
| HEIGHT | MM | 1600 | |||||||||||
| TOTAL POWER | KVA | 15 | |||||||||||
